MIJING WLS-301 LASER Heat Gun INTELLIGENT  HotGun STATION

Video Link: https://vimeo.com/665532535

Caution

• Do not stare at human eyes with the laser pen head or aim the laser pen at other parts of the human body
• Do not violently hit the machine
• When the machine is not working, please cut off the power supply in time. Try not to store flammable and explosive materials near the pen head
• When using this product, please use a triangular plug with a grounding function
• In order to ensure the normal use of the machine, please do not disassemble the machine privately and change the internal and external structure of the equipment
• In order to ensure the normal use of the machine, the laser fiber optic cable cannot be bent 90°, otherwise, it will easily cause the fiber optic cable to be damaged

Parameters

• Laser power: 15W*2, 10 levels adjustable
• Laser spot size:10mm/6mm
• Cooling method: air cooling
• Power：100-220V±10%，50HZ/60HZ±5%
• Machine size:216*110*129

Use introduction

• POWER UP is to increase power(10 levels adjustable)
• POWER down is to reduce power(10 levels adjustable)
• MIJING WLS-301 LASER Heatgun machine is equipped with two memory buttons, CH1 and CH2 (long press for 3 seconds to save), you can set two groups of power parameters that you commonly use.
• The height range of the handheld laser pen is 0-100mm. Exceeding the range will affect the energy.
• The laser is controlled by a foot switch, the laser appears when you step on it, and it disappears when you release it
